Lýsing
Tæknilegar upplýsingar
| All measurements are made at 120V / 240V //50Hz / 60Hz | |
| Amplifier section | |
| Clipping point of the preamplifier is set to a level where total harmonic distortion (THD) is 0.2% | |
| Input Impedance (Fixed) | 330 kohm |
| Output Impedance (20 Hz-20kHz) | < 0,009 Ohm |
| Frequency response (DC – 65 kHz) | – 0.4 dB |
| Input level for rated output | 1 V RMS |
| Max. peak current | > 150 A |
| THD(measured at 1 kHzhalf power,8W) | < 0,001 % |
| THD (measured at 1 kHz -1 dB, 8 W) | < 0,0015 % |
| Noise (measured with bothinputsshorted) |
400 Hz – 30 kHz : 150 µV DC – 30 kHz : 200 µV |
| Damping factor (20 Hz – 20 kHz) | > 850 |
| Rated output power | |
| 8 ohms | 600 W |
| 4 ohms | 1200 W |
| Power consumption (no load or signal) | 230 W |
| The NEMO is DC coupled from input to output | |
| Dimensions | |
| Width | 465 mm / 18.3 inches |
| Depth | 450 mm / 17.7 inches |
| Height | 288 mm / 11.3 inches |
| Weight | 41 kg. / 90.2 lbs. |
FLOATING TRANSFORMER TECHNOLOGY
A first class overall circuit design and state-of-the-art components.
PREMIUM QAULITY
100% MADE IN NORWAY
Every system is produced in our cutting-edge facilities on the west coast of Norway. Unlike other manufacturers, it is not only the design and assembly but also the complete production of the parts and components that is performed here. Producing the entire system right here in Norway allows us to ensure the highest possible quality.
